Features
– Operated by electronic control broad with alternate and parallel function.
– Three levels detection in ground water tank: Start – Low cut off – Common.
– Have time delayer to prolong pumps operation after pressure switch working.
– Alarm buzzer/lamp: Low level – Overload 1 – Overload 2.
– All components are installed on common base fabricated by channel steel.
– Inverter controller is available upon request.
– Optional protection: Dry running protection.

Applications
– Domestic high-rise building, Apartment
– Hotel, Commercial building, Department store
– Factories, Industrial application
– Hospital, University, School

Manifold Dis. DN : 25 – 100 mm
Flow rate : Up to 28 m3/hr
Liquid type and temp : Clean water, ≤ 60 °C
Head : Up to 52 m
Power : Up to 5.5 kw (AC, 380V, 50Hz, 3 Phase)
Pressure tank capacity : 100L/ 200L/ 300L/ 500L/ 750/L (refer to model)
